Eizo FlexScan S2202W User Manual

35
Chapter 5 Reference
5-4 Preset Timing
Thefollowingtableshowsfactorypresetvideotiming(foranalogsignalonly).
Mode Dot clock
Frequency
Polarity
Horizontal: kHz
Vertical: Hz
VGA 640×480@60Hz 25.2 MHz
Horizontal 31.47 Negative
Vertical 59.94 Negative
VGA TEXT
720×400@70Hz
28.3 MHz
Horizontal 31.47 Negative
Vertical 70.09 Positive
VESA 640×480@72Hz 31.5 MHz
Horizontal 37.86 Negative
Vertical 72.81 Negative
VESA 640×480@75Hz 31.5 MHz
Horizontal 37.50 Negative
Vertical 75.00 Negative
VESA 800×600@56Hz 36.0 MHz
Horizontal 35.16 Positive
Vertical 56.25 Positive
VESA 800×600@60Hz 40.0 MHz
Horizontal 37.88 Positive
Vertical 60.32 Positive
VESA 800×600@72Hz 50.0 MHz
Horizontal 48.08 Positive
Vertical 72.19 Positive
VESA 800×600@75Hz 49.5 MHz
Horizontal 46.88 Positive
Vertical 75.00 Positive
VESA 1024×768@60Hz 65.0 MHz
Horizontal 48.36 Negative
Vertical 60.00 Negative
VESA 1024×768@70Hz 75.0 MHz
Horizontal 56.48 Negative
Vertical 70.07 Negative
VESA 1024×768@75Hz 78.8 MHz
Horizontal 60.02 Positive
Vertical 75.03 Positive
VESA 1152×864@75Hz 108.0 MHz
Horizontal 67.50 Positive
Vertical 75.00 Positive
VESA 1280×960@60Hz 108.0 MHz
Horizontal 60.00 Positive
Vertical 60.00 Positive
VESA 1280×1024@60Hz 108.0 MHz
Horizontal 63.98 Positive
Vertical 60.02 Positive
VESA 1280×1024@75Hz 135.0 MHz
Horizontal 79.98 Positive
Vertical 75.03 Positive
VESA CVT
1680×1050@60Hz
146.3 MHz
Horizontal 65.29 Negative
Vertical 59.95 Positive
VESA CVT RB
1680×1050@60Hz
119.0 MHz
Horizontal 64.67 Positive
Vertical 59.88 Negative
Attention
• Display position may be deviated
depending on the PC connected,
which may require screen adjustment
usingAdjustmentmenu.
• If a signal other than those listed in
the table is input, adjust the screen
usingtheAdjustmentmenu.However,
screen display may still be incorrect
evenaftertheadjustment.
• When interlace signals are used, the
screen cannot be displayed correctly
even after screen adjustment using the
Adjustmentmenu.
