Configuration
[61]
• USB cable
• Sensor is not installed in the machine.
The start point for the calibration – maximum gap between measuring target and sensor
including the initial air gap
(1)
– depends on the selected sensor type.
Table 8-1
lists the
start points depending on the sensor and the configured extended range factor
(Measurement > Extended range factor). The initial air gap
(1)
for EZ 105x and 33010x sensors is
0.25 mm and for EZ 1080 sensors 0.5 mm.
Table 8-1: Start point
Sensor
Start point (maximum distance between measuring target and
sensor)
Extended range
factor 1.0
Extended range
factor 1.5
Extended range
factor 2.0
EZ 105x 1.25 mm 1.75 mm 2.25 mm
EZ 108x 2.5 mm 3.5 mm 4.5 mm
33010x 2.25 mm --- ---
Procedure
1. Click Next to send the already entered configuration data to the EZ 1000.
CAUTION!
Connections to external devices may be interrupted when sending configurations.
The output voltage of the EZ 1000 is set to > -1.5 V during this process.
The sending progress is displayed.
2. Click Next.
Step 1
and
Step 2
are skipped if an already configured converter is connected and the
parameters of the dialogs Basic, Input, and Measurement are unchanged.
3. Enter the expected temperature at the sensor mounting location as exact as
possible. If sensor and converter have the same temperature, use the button in
the dialog to measure the internal temperature of the converter. This step is only
necessary if an EZ 105x or an EZ 108x sensor is connected to the EZ 1000 converter.
(1)
Non-linear range at the beginning of the total measuring range of the sensor, before the beginning of the linear measuring range.
