Technical data
[91]
• No ambient temperature change of EZ 1000 during 1 hour before measurement,
power and sensor connected to EZ 1000 for at least 10 minutes before
measurement and calibration.
• WayCon reference target material is 42CrMo4 (AISI 4140), unless otherwise stated.
Note
For measurements that require a higher measuring accuracy, factory calibrated measuring chains are
available.
Accuracy of measuring chains different from the standard measuring chain
Add the measurement inaccuracies in Table 11-2 to the values in Table 11-1 to get the
accuracy of measuring chains different from the standard measuring chain.
Table 11-2: Additional inaccuracies – DSL
Parameter
Additional
Measurement
Inaccuracy (DSL),
Test range
Additional
Measurement
Inaccuracy (DSL),
Operating range Remarks
Cable length 1 m + 3 m
Manual calibration 8.25% 8.25%
Automatic calibration 0.75% 0.75%
Multipoint calibration 0.0% 0.75%
Cable length 1 m + 7 m
Manual calibration 2.75% 2.75%
Automatic calibration
0.75% 0.75%
Multipoint calibration 0.0% 0.75%
Other cable lengths
Manual calibration 0.75% 0.75%
Automatic calibration 0.75% 0.75%
Multipoint calibration
0.0% 0.75%
Other target materials 2.25% 2.25% Material selected from
Machine Studio material
table
Extended measuring
range: 1.5 mm
(Extended range factor:
1.5)
Manual calibration
1.75% 2.0%
Automatic calibration 1.75% 2.0%
Multipoint calibration 0.25% 0.5%
