DVC6000f Series
March 2006
5-62
Table 5-17. Transducer Block, View 3.2
Index Number Parameter
1 ST_REV
74.1 INST_ALERTS_ACTIVE.ELECT_ACTIVE
74.2 INST_ALERTS_ACTIVE.SENSOR_ACTIVE
74.3 INST_ALERTS_ACTIVE.ENVIRO_ACTIVE
74.4 INST_ALERTS_ACTIVE.TRAVEL_ACTIVE
74.5 INST_ALERTS_ACTIVE.PROX_ACTIVE
74.6 INST_ALERTS_ACTIVE.TVL_HISTORY_ACTIVE
74.7 INST_ALERTS_ACTIVE.PERF_ACTIVE
74.8 INST_ALERTS_ACTIVE.PD_EVENT_ACTIVE
74.9 INST_ALERTS_ACTIVE.PD_DETAIL1_ACTIVE
74.10 INST_ALERTS_ACTIVE.PD_DETAIL2_ACTIVE
74.11 INST_ALERTS_ACTIVE.PD_DETAIL3_ACTIVE
74.12 INST_ALERTS_ACTIVE.PD_DETAIL4_ACTIVE
74.13 INST_ALERTS_ACTIVE.PD_DETAIL5_ACTIVE
78 SELFTEST_STATUS
79 HEALTH_INDEX
86.1 DEVICE_RECORD.TEMP_MAX
86.2 DEVICE_RECORD.TEMP_MAX_TIME
86.3 DEVICE_RECORD.TEMP_MIN
86.4 DEVICE_RECORD.TEMP_MIN_TIME
86.5 DEVICE_RECORD.SUPP_PRESS_MAX
86.6 DEVICE_RECORD.SUPP_PRESS_MAX_TIME
86.7 DEVICE_RECORD.SUPP_PRESS_MIN
86.8 DEVICE_RECORD.SUPP_PRESS_MIN_TIME
Table 5-18. Transducer Block, View 4.1
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
10 TRANSDUCER_TYPE
22 ACT_MAN_ID
23 ACT_MODEL_NUM
24 ACT_SN
25 VALVE_MAN_ID
26 VALVE_MODEL_NUM
Table 5-19. Transducer Block, View 4.2
Index Number Parameter
1 ST_REV
27 VALVE_SN
28 VALVE_TYPE
29 XD_CAL_LOC
30 XD_CAL_DATE
31 XD_CAL_WHO
89 TEMPERATURE_UNITS
90 PRESSURE_UNITS
91 TVL_UNITS
92 LENGTH_UNITS
93 AREA_UNITS
94 SPRING_RATE_UNITS
Table 5-20. Transducer Block, View 4.3
Index Number Parameter
1 ST_REV
39 PWA_SIMULATE
41.1 TVL_PRESS_CONTROL.TVL_PRESS_SELECT
41.2 TVL_PRESS_CONTROL.TVL_PRESS_STATE
42.1 BASIC_SETUP.ACTUATOR_STYLE
42.2 BASIC_SETUP.ZERO_PWR_COND
42.3 BASIC_SETUP.TRAVEL_SEN_MOTION
42.4 BASIC_SETUP.FEEDBACK_CONN
42.5 BASIC_SETUP.RELAY_TYPE
42.6 BASIC_SETUP.MAX_SUPP_PRESS
42.7 BASIC_SETUP.PRESS_RANGE_HI
42.8 BASIC_SETUP.PRESS_RANGE_LO
42.9 BASIC_SETUP.TVL_CAL_TRIGGER
42.10 BASIC_SETUP.TVL_TUNING_SET
42.11 BASIC_SETUP.PRESS_TUNING_SET
44.1 TRAVEL_TUNE.TVL_INTEG_ENABLE
44.2 TRAVEL_TUNE.TVL_INTEG_LIM_HI
44.3 TRAVEL_TUNE.TVL_INTEG_LIM_LO
44.4 TRAVEL_TUNE.TVL_INTEG_DEADZ
44.5 TRAVEL_TUNE.TVL_MLFB_GAIN
47.1 PRESS_TUNE.PRESS_CUTOFF_HI
47.2 PRESS_TUNE.PRESS_CUTOFF_LO
47.3 PRESS_TUNE.PRESS_PROP_GAIN
47.4 PRESS_TUNE.PRESS_INTEG_GAIN
47.5 PRESS_TUNE.PRESS_RATE_GAIN
47.6 PRESS_TUNE.PRESS_INTEG_DEADZ
47.7 PRESS_TUNE.PRESS_INTEG_HI_LIM
47.8 PRESS_TUNE.PRESS_INTEG_LO_LIM
47.9 PRESS_TUNE.PRESS_INTEG_IC_HI
47.10 PRESS_TUNE.PRESS_INTEG_IC_LO
47.11 PRESS_TUNE.PRESS_MLFB_GAIN
62 FAILED_ENABLE
63 MAINT_ENABLE
64 ADVISE_ENABLE
65 FAILED_MASK
66 MAINT_MASK
67 ADVISE_MASK
68 FAILED_PRI
69 MAINT_PRI
70 ADVISE_PRI
5
