Reference Manual

00809-0100-4108, Rev BA

Section 2: Configuration

March 2014

Configuration

Table 2-1. Rosemount 2088 device revisions and files

2.4 Configuration basics

The Rosemount 2088 can be configured either before or after installation. Configuring the

transmitter on the bench using either a field communicator, AMS Device Manager, or Local

Operator Interface (LOI) ensures all transmitter components are in working order prior to

installation. Verify that the security switch is set in the unlock position ( ) in order to proceed

with configuration. See Figure 4-2 on page 41 for switch location.

2.4.1 Configuring on the bench

To configure on the bench, required equipment includes a power supply, and a field

communicator, AMS Device Manager, or an LOI (option M4). Wire equipment as shown in

Figure 2-1 below. To ensure successful HART communication, a resistance of at least 250 s

must be present between the transmitter and the power supply, see “Power supply” on page 45

for details. Connect the field communicator leads to the terminals labeled “COMM” on the

terminal block or 1-5V configuration, wire as shown in Figure 2-1 on page 10. The Field

communicator is connected to the terminals labeled VOUT/COMM.

Identify device Find device driver

Review

instructions

Review

functionality

Software

release date

NAMUR

software

revision

(1)

(1) NAMUR Software Revision is located on the hardware tag of the device.

HART

software

revision

(2)

(2) HART Software Revision can be read using a HART capable configuration tool.

HART

universal

revision

Device

revision

(3)

(3) Device Driver file names use Device and DD Revision, e.g. 10_01. HART Protocol is designed to enable legacy device driver revisions to continue to communicate with

new HART devices. To access new functionality, the new Device Driver must be downloaded. It is recommended to download new Device Driver files to ensure full

functionality.

Manual

document

number

Changes to

software

January 2013

1.0.0 01 7 10 00809-0100-4108 See footnote

(4)

for list of changes.

(4) HART Revision 5 and 7 Selectable, Local Operator Interface, Scaled Variable, Configurable Alarms, Expanded Engineering Units.
