13
Reference Manual
00809-0100-4108, Rev BA
Section 2: Configuration
March 2014
Configuration
Fast key sequences for the latest DD are shown in Tab le 2- 3. For Fast Key sequences for legacy
DD's contact your local Emerson Process Representative.
Table 2-3. Rosemount 2088 device dashboard Fast Key sequence
2.5.2 Verifying configuration with AMS Device Manager
Right click on the device and select Configuration Properties from the menu. Navigate the
tabs to review the transmitter configuration data.
2.5.3 Verifying configuration with local operator interface
Press any configuration button to activate the LOI. Select VIEW CONFIG to review the below
parameters. Use the configuration buttons to navigate through the menu.
The parameters to be
reviewed prior to installation include:
2.5.4 Verifying process variables configuration
This section describes how to verify that the correct process variables are selected.
Verifying process variables with a field communicator
Verifying process variables with AMS Device Manager
1. Right click on the device and select Overview from the menu.
2. Click the All Variables button to display the primary, secondary, tertiary and quaternary
variables.
From the HOME screen, enter the Fast Key sequences listed
Function
Fast Key sequence
HART 7 HART 5
Alarm and Saturation Levels 2, 2, 2, 5 2, 2, 2, 5
Damping 2, 2, 1, 1, 5 2, 2, 1, 1, 5
Primary Variable 2, 1, 1, 4, 1 2, 1, 1, 4, 1
Range Values 2, 1, 1, 4 2, 1, 1, 4
Ta g 2, 2, 7, 1, 1 2, 2, 7, 1, 1
Transfer Function 2, 2, 1, 1, 6 2, 2, 1, 1, 6
Units 2, 2, 1, 1, 4 2, 2, 1, 1, 4
 Tag  Primary Variable
 Units  Range Values
 Transfer Function  Damping
 Alarm and Saturation Levels
From the HOME screen, enter the Fast Key
sequence
Device Dashboard Fast Keys
3, 2, 1
