Reference Manual
00809-0100-4108, Rev BA
Section 2: Configuration
March 2014
Configuration
The Rosemount 2088 is set to address zero (0) at the factory, which allows operation in the
standard point-to-point manner with a 4–20 mA output signal. To activate multidrop
communication, the transmitter address must be changed to a number from 1 to 15 for HART
Revision 5, or 1-63 for HART Revision 7. This change deactivates the 4–20 mA analog output,
sending it to 4 mA. It also disables the failure mode alarm signal, which is controlled by the
upscale/downscale switch position. Failure signals in multidropped transmitters are
communicated through HART messages.
2.11.1 Changing a transmitter address
To activate multidrop communication, the transmitter poll address must be assigned a number
from 1 to 15 for HART Revision 5, and 1-63 for HART Revision 7. Each transmitter in a
multidropped loop must have a unique poll address.
Changing transmitter address using a field communicator
Changing transmitter address using AMS Device Manager
1. Right click on the device and select Configure.
2. In HART Revision 5 mode:
a. Click on Manual Setup, select the HART tab.
b. In the Communication Settings box enter polling address in the Polling Address box,
click Send.
3. In HART Revision 7 mode:
a. Click on Manual Setup, select the HART tab and click the Change Polling Address
button.
4. Carefully read the warning and click Yes if it is safe to apply the changes.
2.11.2 Communicating with a multidropped transmitter
To communicate with a multidrop transmitter, the Field Communicator or AMS Device Manager
has to be set up for Polling.
Communicating with a multidropped transmitter using a field
communicator
1. Select Utility and Configure HART Application.
2. Select Polling Addresses.
3. Enter 0-63.
Communicating with a multidropped transmitter using AMS
device manager
From the HOME screen, enter the Fast Key
sequence
HART Revision 5 HART Revision 7
Device Dashboard Fast Keys
2, 2, 5, 2, 1 2, 2, 5, 2, 2
