C.5 LOI menu tree
LOOP TEST
SET 4 MA
SET 20 MA
SET CUSTOM
END LOOP TEST
BACK TO MENU
EXIT MENU
ENTER VALUES
LRV
URV
BACK TO MENU
EXIT MENU
VIEW CONFIG
TAG
PV
UNITS
SENSOR 1 TYPE
CONNECTION
SENSOR 2 TYPE
CONNECTION
UPPER RANGE VALUE
LOWER RANGE VALUE
DAMPING VALUE
HIGH ALARM
LOW ALARM
HIGH SATURATION
LOW SATURATION
BACK TO MENU
EXIT MENU
SENSOR CONFIG
VIEW SENSOR
SENSOR CONFIG
BACK TO MENU
EXIT MENU
UNITS
CHNG ALL
SENSOR 1 UNITS
SENSOR 2 UNITS
DIFFRNTL UNITS
AVERAGE UNITS
1ST GOOD UNITS
BACK TO MENU
EXIT MENU
DISPLAY
SENSOR 1 (on/off)
SENSOR 2 (on/off)
ANALOG (on/off)
PV (on/off)
AVG (on/off)
1ST GD (on/off)
DIFF (on/off)
RANGE % (on/off)
MINMAX 1 (on/off)
MINMAX 2 (on/off)
MINMAX 3 (on/off)
MINMAX 4 (on/off)
BACK TO MENU
EXIT MENU
EXTENDED MENU
CALIBRAT
DAMPING
VARIABLE MAP
TAG
ALM SAT VALUES
PASSWORD
SIMULATE
HART REV
HOT BACK CONFIG
DRIFT ALERT
TC DIAG CONFIG
MIN MAX TRACK
BACK TO MENU
EXIT MENU
RERANGE
ENTER VALUES
BACK TO MENU
EXIT MENU
SENSOR CONFIG
SENSOR 1 CONFIG
SENSOR 2 CONFIG
BACK TO MENU
EXIT MENU
LOI MENU
VIEW CONFIG
SENSOR CONFIG
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXIT MENU
