Reference Manual
00809-0200-4728, Rev SA
Configuration
July 2018
Configuration
Field Communicator
From the HOME screen, enter the Fast Key sequence.
AMS Device Manager
1. Right click on the device and select Configure.
2. In the left navigation pane select Manual Setup.
3. On the Device Tab there will be a group box called Identification, in the box find the fields Tag, Date,
Descriptor and Message, and enter the desired characters.
4. Select Apply when complete.
LOI
Reference Figure 2-18 to find the tag configuration path in the LOI.
Figure 2-18. Configuring the Tag with LOI
2.10 Configure measurement filtering
2.10.1 50/60 Hz filter
The 50/60 Hz Filter (also known as Line Voltage Filter or AC Power Filter) function sets the transmitter
electronic filter to reject the frequency of the AC power supply in the plant. The 60 or 50 Hz mode can be
chosen. The factory default for this setting is 50 Hz.
Field Communicator
From the HOME screen, enter the Fast Key sequence.
Device Dashboard Fast Keys
1, 8
Device Dashboard Fast Keys
2, 2, 7, 4, 1
CALIBRAT
DAMPING
VARIABLE MAP
TAG
TAG
ALM SAT VALUES
PASSWORD
....
VIEW CONFIG
SENSOR CONFIG
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXTENDED MENU
EXIT MENU
