Configuration
LOI
Follow flow chart to select the desired mapped variables. Use the SCROLL and ENTER buttons to select
each variable. Save by selecting SAVE as indicated on the LCD screen when prompted. See Figure 2-4 on
page 12 for an example of a mapped variable with the LOI.
Figure 2-4. Mapping Variables with LOI
2.6.2 Configuring the sensor(s)
Sensor configuration includes setting the information for:
 Sensor type
 Connection type
 Units
 Damping values
 Sensor serial number
 RTD 2-wire offset
Field Communicator
The configure sensors method will guide you through the configuration of all necessary settings
associated with configuring a sensor including:
For a full list of Sensor Types available with the Rosemount 644 Transmitter and their associated levels of
accuracy.
From the HOME screen, enter the Fast Key sequence.
AMS Device Manager
1. Right click on the device and select Configure.
2. In the left navigation pane select Manual Setup and select the Sensor 1or Sensor 2 tab depending
on the need.
3. Individually select the sensor type, connection, units and other sensor related information as desired
from the drop down menus on the screen.
4. Select Apply when complete.
Device Dashboard Fast Keys
2, 1, 1
CALIBRAT
DAMPING
VARIABLE MAP
VARIABLE MAP
TAG
ALM SAT VALUES
PASSWORD
....
RE-MAP PV
RE-MAP 2V
RE-MAP 3V
RE-MAP 4V
....
VIEW CONFIG
SENSOR CONFIG
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXTENDED MENU
EXIT MENU
