8 − 34
Section 8 • Spare Parts List
VSS/VSR/VSM/VSH/VSSH Compressor • Installation, Operation and Service Manual • Emerson • 35391S
Vilter parts get renewed from time to time, so be sure to ask if the part listed in your manual is still the best for your compressor.
Parts that appear on diagrams might be shown separately for reference, but are sold as an assembly or kit only.
Shaft Seal
ITEM DESCRIPTION
MODEL NUMBER
QTY VSM 301-401 VSM 501-701
* SHAFT SEAL KIT (AMM) 219, 230, & 260 1 KT709D KT709A
* SHAFT SEAL KIT (HALO) 219, 230, & 260 1 KT781D KT781A
219 SHAFT SEAL. 1 A A
230 OIL SEAL. 1 2930C 25040A
244 TEFLON SEAL 1 25939A 25939A
252 RETAINER RING 1 2928M 2928M
260 O-RING 1 2176U 2176F
261 O-RING (205 Only) 1 2176AE N/A
NOTES
* Not pictured.
A Sold only as kit.
