Section 5 • Maintenance/Service
VSS/VSR/VSM/VSH/VSSH Compressor • Installation, Operation and Service Manual • Emerson • 35391S
VILTER
TM
PART NO
VOLTAGE Hz HOLDING CONNECTION PILOT LIGHT
3389DA 110-120VAC 60 14W DIN
3389DB 110-120VAC 60 14W DIN GREEN
3389DC 110VAC 60 12W TERMINAL BOX GREEN
3389DD 220VAC 60 12W TERMINAL BOX GREEN
3389DD1 220VAC W/110VAC
LED BOX
60 12W - LED
VILTER
TM
PART NO
DESCRIPTION
3389EA ICAD 600 MOTOR ACTUATOR W/10M CABLES
3389EE ICAD 900 MOTOR ACTUATOR W/10M CABLES
3389AE1 CABLES, 10M FOR ICAD ACTUATOR
3389AE2 TOP COVER FOR ICAD ACTUATOR
3389EB CONTROLLER EKC 347, LIQUID LEVEL
3389FD MODULE B66 FUNCTION (FOR ICF VALVE STATION)
3389FA MAGNETIC TOOL FOR ICM VALVE MANUAL OPERATION 20,25, AND 32
3389FC MAGNETIC TOOL FOR ICM VALVE MANUAL OPERATION 40, 50, AND 65
3389FB ICM 20 SERVICE KIT (VALVE SEAT)
3389FE ICM 25 SERVICE KIT (VALVE SEAT)
3389FF ICM 32 SERVICE KIT (VALVE SEAT)
Table 5-10. Coils for Solenoid Valves (ICFE)
Table 5-11. Parts for Motorized Valve Station (ICF)
