Create the Map and Install the PV Modules and Enphase Microinverters
If you installed an Enphase PV system at this site, create the Enphase installation map and install the PV
modules and Enphase Microinverters. You will scan this map later using Installer Toolkit and your mobile
device. (See “Method A: Provision Devices with Installer Toolkit” on page 18.)
NOTE: You can find an Enphase installation map at the back of any Enphase Microinverter
manual.
Create a paper installation map to record Enphase Microinverter (and Enphase Battery, if
installed) serial numbers and positions in the array. Peel the removable serial number label
from each device and affix it to the respective location on the installation map.
Peel the removable label from the bottom of the Envoy-S and affix it to the installation map.
Always keep a copy of the installation map for your records.
NOTE: If you are setting up the Envoy-S to monitor a non-Enphase PV system, you do not
need to create an Enphase installation map.
