ePropulsion SPIRIT 1.0 User Manual

- 18 -
Step4:
Turn the throttle form zero position to desiring direction to start the
outboard motor. Change the heading direction of the boat by turning the
tiller on horizontal level.
Backward
Forward
Figure 4-4
4.3 Stopping
The outboard can be stopped in one of the following four ways.
 Turn throttle to zero position.  Remove the magnetic key.
1
2
 Switch off the power button.  Disconnect the power cable.

ePropulsion SPIRIT 1.0 Specifications

General

Power	1 kW
Battery Type	Lithium-ion
Battery Capacity	1276 Wh
Control	Tiller
Propulsion	Electric
Battery Weight	8.7 kg
Rated Power	1 kW
Comparable Petrol Outboard	3 HP
Nominal Voltage	48 V
Voltage	48 V
Shaft Length	Short, Long
Motor Type	Brushless DC
Max Speed	5 knots (with standard battery)
Charging Time	8.5 hours
