- 19 -
In normal operating procedure, it’s recommended to stop the outboard as
following steps.
1. Rotate the throttle to zero position.
2. Wait until the outboard stops, then remove the magnetic key from tiller.
3. Press and hold(≥2secs) the “POWER” button to power off system.
4. Tilting the outboard out of the water or uninstall it from boat according
to your requirement.
In abnormal situations like a fall over emergency, it’s recommended to stop
the outboard motor by removing the magnetic key from the tiller.
In malfunction situations, the outboard will stop immediately for protection.
The outboard will stop if one of the following situations occurs.
1) The throttle is in zero position.
2) The power button is switched off. By pressing the power button.
3) The magnetic key is removed.
4) The connection between tiller and battery is broken.
5) The battery is out of charge.
6) The outboard goes malfunction (e.g. motor blocked or the battery
voltage drops lower than 33V).
It’s recommended to tilt up the outboard out of water when the motor
is not running.
4.4
Tiller Adjustment
The tiller of SPIRIT 1.0 is adjustable on both horizontal and vertical direction.
Pulling up the tiller
P
ull up the tiller if necessary during operation.
