- 32 -

Propeller Assembling

The propeller type affects the performance of outboard critically. Users can

select a proper propeller according to different applications. For a larger load

boat and a low running speed, a smaller-pitch propeller is more suitable.

Inversely, for a smaller load boat and a fast running speed, a large-pitch one

is more suitable. Contact your dealer on propeller selection.

Step1: Attach the washer.

Step2: Fix the pin to the hole on motor

shaft.

Step3: Attach the propeller.

Step4: Attach the disc

spring.

Step5: Tighten the

nut with 17mm

socket wrench.

Figure 8-1
