ePropulsion SPIRIT 1.0 User Manual

- 21 -
4.5 Tilting up the Outboard Motor
Toggle up the tilt handle once, then take the battery handle to tilt up the
outboard motor to maximum height. After a click sound, release the battery
handle and the outboard will stay at a position of 75° trim angle.
Hold the battery handle and toggle up the tilt handle once again, users can
lay down the outboard gently to the original position in water.
Tilt Handle
Figure 4-7
Figure 4-8
Never toggle the tilt handle when the propeller is rotating.
Slight and gentle operations are recommended when tilting up and
down.

ePropulsion SPIRIT 1.0 Specifications

General

Power	1 kW
Battery Type	Lithium-ion
Battery Capacity	1276 Wh
Control	Tiller
Propulsion	Electric
Battery Weight	8.7 kg
Rated Power	1 kW
Comparable Petrol Outboard	3 HP
Nominal Voltage	48 V
Voltage	48 V
Shaft Length	Short, Long
Motor Type	Brushless DC
Max Speed	5 knots (with standard battery)
Charging Time	8.5 hours
