- 22 -

4.6

Fixing of Steering

Put the front fix pin into the hole (shown in Figure 4-11) can fix the steering,

and the rotation of tiller on horizontal level will be disabled. Use the pin if

necessary.

Put the

pin into

the hole

Steering Drection Fixed in Front

Figure 4-9 Figure 4-10

4.7

Fixing for Porting

Put the

pin into

the hole

Figure 4-11

By rotating the tiller with 180 degrees from the status of Figure 4-10, the fix pin

can be put into another hole. It is aimed to prevent the rotation of tiller during

porting or transportation so the process maybe more conveniently.
