104
6. Use the arrow buttons on the projector or the remote control to select the corner or side of the image
you want to adjust. Then press Enter.
7. Press the arrow buttons to adjust the image shape as necessary.
8. When you are finished, press Esc.
Parent topic: Image Shape
Correcting Image Shape with Point Correction
You can use the projector's Point Correction feature to fine-tune the image shape using points on a grid.
This is useful for adjusting overlapping areas in multiple projected images that do not line up correctly.
Note: If you change the Screen Type or Screen Position settings, your image adjustments are reset.
1. Turn on the projector and display an image.
2. Press the Menu button.
3. Select Installation > Geometry Correction > Point Correction.
Note: If you see a confirmation message, select Yes and press Enter.
4. Select the Point Correction setting again and press Enter.
Note: For fine tuning, select Quick Corner to roughly correct the shape and size of an image and
then select Point Correction to adjust them more precisely.
5. Select the number of grid lines to display and press Enter.
You see a grid on the projected image.
Note: If you need to change the color of the grid lines, press Esc and then select a different Pattern
Color setting in the Point Correction menu.
