Epson PowerLite EB-L210SF User Manual

270
Supported Video Display Formats
For best results, your computer's monitor port or video card resolution should be set to display in the
projector's native resolution. However, your projector includes Epson's SizeWise chip that supports other
computer display resolutions, so your image will be resized to fit automatically.
Your computer's monitor port or video card refresh rate (vertical frequency) must be compatible with the
projector. (See your computer or video card manual for details.)
The table here lists the compatible refresh rate and resolution for each compatible video display format.
Display format Refresh rate (in Hz) Resolution (in pixels)
Computer signals (analog RGB)
VGA 59.94/72/75/85 640 × 480
SVGA 60.32/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
59.79 1366 × 768
59.81/75/85 1280 × 800
WXGA+ 59.89/75/85 1440 × 900
WXGA++ 60 1600 × 900
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 960
60.02/75/85 1280 × 1024
SXGA+ 59.98/75 1400 × 1050
WSXGA+ 59.95 1680 × 1050
UXGA 60 1600 × 1200
WUXGA (Reduced Blanking) 59.95 1920 × 1080
Composite video
TV (480i) 60 720 × 480
TV (576i) 50/60 720 × 576

Epson PowerLite EB-L210SF Specifications

General

DVI port	No
Microphone in	Yes
Audio (L/R) in	1
Composite video in	-
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Matrix size	0.62 \
Heat dissipation	884 BTU/h
Number of colors	1.07 billion colors
White light output	4000 ANSI lumens
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (dynamic)	2500000:1
Screen size compatibility	55 - 125 \
Keystone correction, horizontal	-15 - 15 °
Video color modes	Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB
Supported video modes	1080p
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	27 dB
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Color depth	10 bit
Focus	Manual
Throw ratio	0.45 - 0.61:1
Placement	Ceiling, Desktop, Wall
Product type	Short throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Cord length	1.8 m
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	201 W
Power consumption (economy mode)	191 W
RMS rated power	16 W
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	337 mm
Width	325 mm
Height	90 mm
Weight	4600 g
