Epson PowerLite EB-L210SF User Manual

160
4. Press the left or right arrow button to select Adjustment Level 8.
Note: There are several adjustment levels and you can adjust each level individually.
5. Press the left or right arrow buttons to adjust the Brightness setting.
6. Press the left or right arrow buttons to adjust the color tone for the Red, Green, and Blue settings if
necessary.
7. Press Esc to return to the Multi-Projection menu.
8. Select the Operation menu and press Enter.
9. Select Light Source Brightness Control and press Enter.
10. Set the Light Source Mode setting to Custom and adjust the Brightness Level setting as
necessary.
11. Press Esc and repeat steps 2 through 6 for Adjustment Level 7 through 2.
12. When you are finished, press the Menu button.
Parent topic: Using Multiple Projectors
Adjusting the Black Level
When two images overlap, the overlapping area can appear differently from the areas that do not
overlap. You can use the projector's Black Level setting to make the difference less noticeable (EB-
L210SF).

Epson PowerLite EB-L210SF Specifications

General

DVI port	No
Microphone in	Yes
Audio (L/R) in	1
Composite video in	-
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Matrix size	0.62 \
Heat dissipation	884 BTU/h
Number of colors	1.07 billion colors
White light output	4000 ANSI lumens
Native aspect ratio	16:9
Projection technology	3LCD
Contrast ratio (dynamic)	2500000:1
Screen size compatibility	55 - 125 \
Keystone correction, horizontal	-15 - 15 °
Video color modes	Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB
Supported video modes	1080p
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	27 dB
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Color depth	10 bit
Focus	Manual
Throw ratio	0.45 - 0.61:1
Placement	Ceiling, Desktop, Wall
Product type	Short throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Cord length	1.8 m
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	201 W
Power consumption (economy mode)	191 W
RMS rated power	16 W
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	337 mm
Width	325 mm
Height	90 mm
Weight	4600 g
