Erbe APC 3 Service Manual

57 / 70
7 • Maintenance and servicing
80116-941_V24392  2023-03
Performance test of the optional bipolar socket
Plugging detection Testing and measuring equipment
Test setup
• The test specimen is connected via the VIO 3 electrosurgical unit to the
power supply.
Test procedure
1. Call up <Test Program Plugging recognition>.
2. Plug a 20196-053 bipolar cable into the bipolar socket. The test pro-
gram must perform the following actions on APC 3, slot 1:
– Connector type is detected: Display "not plugged" -> bipolar dis-
play.
– Plugging counter is increased by one: XM (=monopolar connector),
XB (=bipolar connector). The plugging counter can be reset using
"Reset"
3. Unplug cable.
4. Repeat the test with bipolar cable 20196-055.
5. Terminate the test program with <Close>.
6. Exit the Service settings.
AUTO START, bipolar Testing and measuring equipment
Erbe Art. No. Description
20196-053 Bipolar cable, international 2Pin 22
20196-055 Bipolar cable, international 2Pin 28
Erbe Art. No. Description
20196-045 Bipolar cable
or
20196-053 Bipolar cable, international 2Pin 22
20100-034 Adapter cable bipolar
20100-102 VIO Testbox Auto Start/Auto Stop (bipolar
start/stop)
