Erbe APC 3 Service Manual

67 / 70
7 • Maintenance and servicing
80116-941_V24392  2023-03
2. Set HF power meter to:
RL = 100 Ohm
3. Activate test specimen via COAG pedal on the footswitch.
4. Determine and document the measured value. The tolerance range is
96 to 144 watts.
Performance test of the optional MF socket
Instrument recognition Testing and measuring equipment
Test setup
• The test specimen is connected via the VIO 3 electrosurgical unit to the
power supply.
Test procedure
1. Call up <Test Program Instrument recognition>.
2. Plug a 20100-152 measurement cable into the MF socket. The test
program must show the measuring cable data record on APC 3, slot 1.
– Slot naming in test program (MF for MF socket)
3. Terminate the test program with <Close>.
4. Exit the Service settings.
AUTO START thermoSEAL Testing and measuring equipment
Erbe Art. No. Description
20100-152 BiClamp measuring cable
Erbe Art. No. Description
20100-152 BiClamp measuring cable
20100-102 VIO Testbox Auto Start/Auto Stop (bipolar
start/stop)
