LUCREZIA IDRO CLEANING
35
ENGLISH
LUCREZIA IDRO CLEANING21.
Some images could be oset from the original model.
Maintenance operations guarantee correct functioning of the
product through time. Failure to comply with these operations can
jeopardise the safety of the product. The cleaning operations must
be performed when the stove is completely cold.
BURN POT CLEANING21.1.
The burn pot is cleaned via a mechanical system at pre-xed
intervals automatically by the boiler. The gure below shows the
burn pot with underlying opening.
The company recommends to remove any ash residue using a
suction device, at least once every two days.
gure 27
DEFLECTOR CLEANING21.2.
It is necessary to remove the smoke deector located under the
cleaning springs of the heat exchanger every month. To extract it,
follow the procedure below:
remove part A of the door upper deector xed with 3
screws
remove part B of the door upper deector xed with 2
screws
extract the smoke central deector as if it were a drawer
gure 28
gure 29
CLEANING THE ASH DRAWER21.3.
The ash drawer must be emptied at least weekly and however on
the basis of the frequency of use of the machine. Before emptying
the content into an appropriate container, make sure that there are
no hot ashes inside. To open the drawer after having removed the
ash drawer cover, pull the handle as indicated by the arrows.
gure 30
gure 31 gure 32
DOOR GASKET AND ASH DRAWER21.4.
The gaskets guarantee the tightness of the boiler and its consequent
good functioning.
These must be checked regularly: if they should be worn or
damaged they must be replaced immediately.
These operations must be carried out by an authorised technician.
N.B. For correct functioning, the boiler must undergo routine
maintenance by an authorised technician, at least once a year.
If the power supply cable is damaged, it must be replaced by the
after-sales service or by a similarly qualied person, so as to avoid
al risks.
