Fastech Ezi-SPEED ESD-30-C User Manual

-12-
Unit Part Number
Motor Part
Number
Drive Part
Number
Gearhead Part
Number
Gear
Ratio
Ezi-SPEED-104-H-400-C-R15-P
ESG-104-H-R15-P
1:15
Ezi-SPEED-104-H-400-C-R20-P
ESG-104-H-R20-P
1:20
Ezi-SPEED-104-H-400-C-R30-P
ESG-104-H-R30-P
1:30
Ezi-SPEED-104-H-400-C-R50-P
ESG-104-H-R50-P
1:50
Ezi-SPEED-104-H-400-C-R100-P
ESG-104-H-R100-P
1:100
Ezi-SPEED-104-H-400-C-R200-P
ESG-104-H-R200-P
1:200
2.3 Checking the parts
Verify that the items listed below are included. Report any missing or damaged items to sales
office from which you purchased the parts.
Standard Motor and Drive Combinations
• Motor ............................................................................................................................................................................... 1 EA
• Drive ................................................................................................................................................................................. 1 EA
• Connection cable ........................................................................................................................................................ 1 EA
(Only models with a supplied connection cable)
• CN1 connector (5 pins) ............................................................................................................................................ 1 EA
• CN4 connector (13 pins) ......................................................................................................................................... 1 EA
• Earth screw .................................................................................................................................................................... 2 EA
• StartUp Guide .............................................................................................................................................................. 1 EA
Combination type Parallel Shaft Gearhead
• Parallel shaft gearhead ........................................................................................................................................... 1 EA
• Hexagonal socket head bolt set ....................................................................................................................... 1 SET
(Bolt, Hexagon nut, Flat washer, Spring washer, 4 pcs each)
• Key .....................................................................................................................................................................................1 EA
• Parallel shaft gearhead operation manual ...................................................................................................... 1 EA
Combination type Hollow Shaft Gearhead
• Hollow shaft gearhead.............................................................................................................................................. 1 EA
• Hexagonal socket head bolt set.......................................................................................................................... 1 SET
(Bolt, Hexagon nut, Flat washer, Spring washer, 4 pcs each)
• Assembly bolts for motor and gearhead ......................................................................................................... 4 EA
