-27-
6. Installing and wiring
6.1 Cautions on installations
1. Be carefull when open package. Otherwise, the product may get damaged or user’s foot may
get injured by dropping the product.
2. This product has been designed for indoor uses. The ambient temperature of the room
should be 0°~ 40°C.
3. If the temperature of the case is 40°C or higher, radiate heat outside for cooling down.
4. Do not install at area direct sun, magnetic object, a radioactive material, explosive material and
toxic gas.
5. Install at area free of dust, iron powder and salt.
6. Install at area not subject to continuous vibration or excessive shocks.
7. Install at area free electronic noise (from welder. power machine, etc)
8. When installing the drive, drive front panel install to front or upper side.
9. Please install drive on flat metal plate with excellent durability against vibration.
10. When installing drive to plate, fixing 2 mountuing holes with roundhead screw and nut (M4 :
Not include). Tighten the screws until no gaps remain between the drive and plate.
11. When installing 2 drives more, there must be a clearance of 20mm or more and 50mm or
more clearance in the horizontal and vertical direction.
