Fastech Ezi-SPEED ESD-30-C User Manual

-13-
• Safety cover .………………..............................................................................................................................................1 EA
• Assembly screw of safety cover(M3)................................................................................................................... 2 EA
• Parallel key …………………………................................................................................................................................... 1 EA
• Hollow shaft gearhead operation manual ....................................................................................................... 1 EA
3. Specifications and dimensions of the drive
3.1 Specifications
Part Number
ESD-60-S-30
ESD-80-S-60
ESD-90-S-
120
ESD-104-S-
200
ESD-104-S-
400
Rated Output
Power(Continuous)
30W
60W
120W
20W
400W
Power
supply
Input
Rated
Voltage
Single-Phase 200~240V / Three-Phase 200~240V
Permissible
Voltage
Range
±10 %
Frequency
50 / 60 Hz
Permissible
Frequency
Range
±5 %
Rated Input
Current
Single-Phase :
0.88A
Three-Phase :
0.51A
Single-Phase :
1.55A
Three-Phase :
0.90A
Single-Phase :
2.43A
Three-Phase :
1.41A
Single-Phase :
3.42A
Three-Phase :
1.97A
Single-Phase :
5.64A
Three-Phase :
3.26A
Maximum
input
Current
Single-Phase :
1.9A
Three-Phase :
1.1A
Single-Phase :
2.8A
Three-Phase :
1.7A
Single-Phase :
4.5A
Three-Phase :
2.6A
Single-Phase :
5.47A
Three-Phase :
3.16A
Single-Phase :
7.85A
Three-Phase :
4.53A
Rated Output Current
0.17 A
0.43 A
0.89 A
1.65 A
2.57 A
Rated Torque
0.096 N*m
0.191 N*m
0.382 N*m
0.637 N*m
1.27 N*m
Maximum
Instantaneous Torque
0.144 N*m
0.287 N*m
0.573 N*m
1.15 N*m
1.91 N*m
Rated Speed
3000 r/min
Speed Control Range
50~4000 r/min
Speed Regulation
0.2% or less / Conditions : 0~Rated Torque, Rated Speed, Rated Voltage,
Normal Temperature
