Fastech Ezi-SPEED ESD-30-C User Manual

-35-
Item
Assembly bolts for
motor and gearhead
Included nut, P/W, S/W
Assembly bolts for
applications
Included nut, P/W, S/W
Assembly bolts for
Safety cover
Key size
(mm)
ESG-60-H-R
□-H
M4*16L
(Hexagonal socket
head bolt)
M5*65L
(Hexagonal socket
head bolt)
M3*8L
(Pan headed
screw)
4*4*25-
1R
ESG-80-H-R
□-H
M6*16L
(Hexagonal socket
head bolt)
M6*70L
(Hexagonal socket
head bolt)
M3*12L
(Pan headed
screw)
5*5*25-
1R
ESG-90-H-R
□-H
M8*20L
(Hexagonal socket
head bolt)
M8*90L
(Hexagonal socket
head bolt)
M3*12L
(Pan headed
screw)
6*6*25-
1R
6.4.2 Cautions on operations
• Checking the part number of motor & gearhead.
• Checking the part number of motor and gearhead that can be assembled.
• When installing gearhead, do not damage the motor shaft.
• Assembly can be done only when motor frame size and gearhead frame size are the same.
• When installing the motor and gearhead, please use the supplied screws.
Install the motor in following conditions
• Operating ambient temperature is 0~40℃, operating ambient humidity is 85% or less
• Area not exposed to direct sun and free of of moisture and grease.
• Area not subject to continuous vibration or shocks or free of dust.
• Area that is free of flammable gas or corrosive gas.
