100

VAC SYS Set SE 1 GB 240V

VAC SYS VP vacuum pump in the SYS 3 SYSTAINER, VAC SYS SE 1

vacuum clamping unit with VAC SYS VT D 215 mm vacuum pad, vacuum

hose and foot valve in SYS 4 SYSTAINER

712257

VAC SYS SE 2

VAC SYS VT 275 x 100 mm vacuum pad, connecting piece, vacuum hose,

in SYS 4 SYSTAINER

580062

Speciﬁcations

Power consumption at 50 Hz (W) 160 – 200

Power consumption at 60 Hz (W) 200 – 230

Pump capacity at 50 Hz (m

/h) 2.7

Pump capacity at 60 Hz (m

/h) 3.5

Minimum vacuum (mbar) ≥ 81%/≥ 810

Weight (kg) 8

VAC SYS Accessories

VAC SYS VT 200 x 60 vacuum pad

for VAC SYS SE 1, VAC SYS SE 2, pad dimensions 200x60mm,

in carton

580064

VAC SYS VT 275 x 100 vacuum pad

for VAC SYS SE 1, VAC SYS SE 2, pad dimensions 275x100 mm,

in carton

580066

VAC SYS VT 277 x 32 vacuum pad

for VAC SYS SE 1, VAC SYS SE 2, pad dimensions 277x32 mm,

in carton

580065

VAC SYS VT D 215 vacuum pad

for VAC SYS SE 1, VAC SYS SE 2, diameter 215 mm, in carton

580067

VAC SYS AD MFT 3 adapter

for VAC SYS SE 1, VAC SYS SE 2, for connecting the VAC SYS clamping

unit with the MFT 3, in carton

494977

VAC SYS VT Sort accessories SYSTAINER

VAC SYS VT 200 x 60, VAC SYS VT 277 x 32, VAC SYS VT 275 x 100,

also provides space for VAC SYS VT D 215, in SYS 3 SYSTAINER

495294

The VAC SYS vacuum clamping system provides even more clamping options and the possibility of working from all sides, in addition to the MFT. It allows

workpieces to be rotated through 360° and swivelled through 90°. The clamping pads are of soft and ﬂexible plastic and are therefore also suitable for
