Use the DOMINO DF 700 for stable frame joints such as for doors,
where larger dominos can be processed for even greater stability.
In this example, a panel door is created with a pinned internal rebate
and additional tenon.
The DOMINO joining machines are unique in that you can set the routed
holes even after rebating, which would not be possible with a classic drill
for conventional domino joints, for example, due to the lack of support
surface. This ‘pinned joint’ requires small deviations in the routing
depth setting, which are explained in the following.
TIP Due to the pinned joint, the 14 x 140 mm domino cannot be
processed despite the maximum routing depth of 70 mm for the
DF 700. The maximum possible standard domino is the 14 x 100 mm.
However, if you wish to make full use of the maximum routing depth
and cut the domino itself to the correct maximum size, you can do
so by cutting the domino to the appropriate length and creating the
perfect domino size yourself.
4.2.3 Stable frame joints with the DF 700
