6.3.3 DOMINO corner and flat connectors
Corner
connectors
Flat connectors
Anchor bolt SV-AB D14/32
32 anchor bolts for corner connections, including 64 domino
connector covers for transferring transverse loads.
201350
Expansion bolt SV-SA D14/32
32 expansion bolts for secure locking.
201349
Transverse anchor SV-QA D14/32
32 transverse anchors including studs for locking anchors
or double-headed bolts.
201351
Enlarger SV-V D14/32
64 domino connector covers for widening 32 transverse anchors.
For widening and pressure distribution when using transverse
anchors in materials such as kitchen worktops.
201498
(optional)
Double-headed bolt SV-DB D14/16
16 double-headed bolts for flat connections, including 64 domino
connector covers. The double-headed bolts can be clipped using
2 domino connector covers or (as shown) with 4 domino connector
covers – depending on the required alignment and transverse load
transmission.
201352
Connector set EV/32-Set
For 32 corner connectors, 32 SV-AB D14 anchor bolts, 32 SV-QA D14
transverse anchors, 32 SV-SA D14 expansion bolts.
201827
Connector set FV/16-Set
For 16 flat connectors, 16 SV-DB D14 double-headed bolts,
32 SV-QA D14 transverse anchors, SV-V D14 enlargers for
32 transverse anchors.
201828
