427-0073-12-12 Version 120 May 2015 2-4
2
Basic Operation and Configuration
2.3.3 Live Video Page
The Live Video page will be displayed, with a live image from the camera on the left part of the
screen. Next to the FLIR logo along the top of the screen are some menu choices, including Live
Video (the red text indicates it is selected), Help, and Log out. The expert and admin logins provide
additional menu choices.
If the live video is not displayed, refer to Troubleshooting Tips, pg. 2-18. In the lower right of the web
page there is a frame rate selector. This selector allows the user to change the rate at which the
frames are displayed in the browser. This rate controls the user’s own web browser only, and does not
affect the video streams to other users or to an NVR. For slow communication links, if there is a
problem displaying the video image, it may help to slow down the frame rate.
Help
At the top of the page, the Help menu displays software version information. This page has
information about the camera including hardware and software revision numbers, part numbers, and
serial numbers. If it is necessary to contact FLIR Technical Support for assistance, it will be helpful to
have the information from this page (such as Software Version) on hand.
Log out
Use this button to disconnect from the camera and stop the display of the video stream. If a web
session is inactive for 20 minutes, it will be stopped and it will be necessary to log in again.
Figure 2-2: Live Video Web Page
Temperature
Temperature
Reading
Snapshot
Video Analytics
Area
Toggle PC/
Camera Time
Alarm
