FLIR Saros DM Series User Manual

Installation
15
427-0200-00-12 Revision 100
November 2019
This document does not contain any export-controlled information.
7. Thread the cables through the outdoor mount kit and attach the mount kit to the wall mount using the
supplied screws and washers.
8. For outdoor cameras, adjust the waterproof gasket to the joint.
9. Connect the cables to the camera. See Camera Connections.
10.Secure the camera to the outdoor mount kit.
CX-CRNR-G3 dimensions
2.4.4.2 Pole Adapter CX-POLE-G3
Pole adapter for CX-xxxx-G3 mounts, including 2.5-8.5 inch straps.
Item
Details
Qty
Pole mount bracket
CX-POLE-G3
1
8.5" ring
3
Accessory bag
Stainless streel truss
head screw M8*20
4
Stainless steel truss
head screw M8*30
4
M8 washer
4
M8 screw nut
4
M8 spring washer
4
Quick install guide
Summarized below
1
