3.2.7 Georeference Page
Use the Georeference page to specify the camera's
geographical location and mounting position.
For geographical location, specify:
o Latitude, in degrees North or South
o Longitude, in degrees East or West
To obtain the camera's latitude and longitude, use a
map or a mobile GPS device.
For mounting position, specify:
o Altitude, in meters above the surrounding ground level (must be greater than zero)
o Orientation: the installation angle of the “zero-pan” line of the camera, between 0-360 degrees from
North
After making any change on the Georeference page, click Save to save the changes.
The camera can report this georeference information via FLIR CGI or ONVIF, which:
·
Allows the user or an application to:
o Show the camera on a map
o Show the direction the camera is facing (using the camera's field of view, which the camera also
reports)
·
Supports pan and tilt cueing. For example, the FLIR CGI protocol provides pan and tilt commands to
point the camera at a specific geographic location (latitude/longitude).
