Focus Firestore FS-100 User Manual

Quickstart
FS-100 Portable DTE Recorder 11
Computer FireWire Connector
• In/Out: 6-pin IEEE-1394a port x 1
• Asynchronous Data I/O
Remote Control, Serial Connector
• GPI / RS232C; 3.5mm TRS mini jack. (3.5mm to DB-9 cable
accessory available).
• Configure as a simple contact closure or RS-232C port.
• Connect an optional wired remote commander.
Camera FireWire Connector
• DV/I/O
• 6-pin IEEE-1394a connector
• Isochronous 25Mb/s to 100Mb/s DV video I/O
FS-100 supports 1080i/720p video I/O in DVCPROHD REC
mode.
• Supported inputs for DVCPROHD / DVCPRO50 / DVCPRO /
DV:
• For DVCPROHD input, audio is embedded 4-ch, 48kHz, 16-
bit.
• For DVCPRO50 input, audio is embedded 4-ch., 48kHz, 16-
bit.
• For DVCPRO input, audio is embedded 2-ch., 48kHz, 16-bit,
• For DV input, audio is embedded 2-ch., 48kHz, 16-bit or 4-ch.,
32-khz, 12-bit.
NTSC
- 1080 60i (30P, 24P, 24PA)
- 720 60P (30P, 24P)
- 480 60i (30P, 24P, 24PA)
- *( ) pull down format - (same stream)
PAL
- 1080 50i (25P)
- 720 50P (25P)
- 576 50i (25P)
- *( ) pull down format - (same stream)
4-Channel Audio
4-channel (12-bit, 32kHz) audio is available only with RawDV
format.
