FS-100 Functions
56 FS-100 Portable DTE Recorder
• When Alarm is set to Off, the audio feedback for the buttons
is disabled, however the alarm will still sound for low power,
high heat, or low disk space conditions.
Stop Frame, No video
These settings determine the FS-100 video output when it is in STOP
mode.
•STOP FRAME
Displays the first frame of the clip.
• STOP NO VIDEO Group Default
Video output is Off.
EXT CTL OFF, Pause, Frame, File
These options permit the use of an external device to control the FS-
100 through the optional RS-232 cable.
• EXT CTL OFF
Use this option when connecting an external device using an
RS232C cable.
• This requires the use of a a 3.5mm-to-DB9 adapter cable,
plugged into FS-100
Control port.
In Local mode, select this item to control the FS-100 with the
optional wired remote control unit.
The following options permit control functions to occur from a
simple contact closure.
• EXT CTL PAUSE
Controls Pause and Resume during a record or playback
session.
• EXT CTL FRAME
Captures a single frame of video and records it to a file. Each
time this function is triggered, it sequentially adds another
frame to the same file until stopped.
RS-232 Cable Available from Focus Online Store
The RS-232 cable required to connect the FS-100 to an external control device
is Focus part number CBLA-0113-01. It and other accessories mentioned in
this manual are available at https://www.focusinfo.com/sales/store.
