Ford Escape 2013 User Manual

NAVIGATION
Note: The navigation SD card must be in
the SD card slot to operate the navigation
system. If you need a replacement SD card,
see your authorized dealer.
Note: The SD card slot is spring-loaded. To
remove the SD card, just push the card in
and release it. Do not attempt to pull the
card out to remove it; this could cause
damage.
Your navigation system is comprised of
two main features, destination mode and
map mode.
To set a destination, press the green corner
of your touchscreen, then the Dest button
when it appears. Refer to Setting a
destination later in this chapter.
To view the navigation map and the
vehicle's current location, touch the green
bar in the upper right hand corner of the
touchscreen, or, press Dest, then Map. refer
to Map mode later in this chapter.
Setting a Destination
Press the green corner of your touchscreen,
then the Dest button when it appears.
Choose any of the following:
Destination
Street AddressMy Home
IntersectionFavorites
City CenterPrevious Destinations
MapPoint of Interest (POI)
Previous Starting PointEmergency
Latitude/LongitudeFreeway Entrance/Exit
1. Enter the necessary information into
the highlighted text fields (in any
order). For address destination entry,
the Go! button appears once all the
necessary information has been
entered. Pressing the Go! button makes
the address location to appear on the
map. If you choose Previous
Destination, the last 20 destinations
you have selected appear.
2. Select Set as Dest to make this your
destination. You can also choose to set
this as a waypoint (have the system
route to this point on the way to your
current destination) or save it as a
favorite. Any Avoid Areas selections are
also considered in route calculation.
3. Choose from up to three different types
of routes, then select Start Route.
• Fastest: Uses the fastest moving roads
possible.
• Shortest: Uses the shortest distance
possible.
• Eco (EcoRoute): Uses the most fuel
efficient route.
371
MyFord Touch®

Ford Escape 2013 Specifications

Curb Weight

curb weight 1.6L FWD	3502 lbs
curb weight 1.6L 4WD	3645 lbs
curb weight 2.0L FWD	3592 lbs
curb weight 2.0L 4WD	3732 lbs
curb weight 2.5L FWD	3515 lbs

Seating and Interior

seating capacity	5
head room front	39.9 inches
head room rear	39.0 inches
shoulder room front	56.0 inches
shoulder room rear	55.3 inches
hip room front	54.8 inches
hip room rear	52.4 inches
leg room front	43.1 inches
leg room rear	36.8 inches

Passenger and Cargo Volume

passenger volume	98.1 cu. ft.
cargo volume behind 1st row	67.8 cu. ft.
cargo volume behind 2nd row	34.3 cu. ft.
total interior volume	132.4 cu. ft.

Fuel

fuel tank capacity	15.0 gallons
fuel requirement	87 octane
fuel economy 2.5L FWD	22/31 mpg (city/hwy)
fuel economy 1.6L FWD	23/33 mpg (city/hwy)
fuel economy 1.6L 4WD	22/30 mpg (city/hwy)
fuel economy 2.0L FWD	22/30 mpg (city/hwy)
fuel economy 2.0L 4WD	21/28 mpg (city/hwy)

Engine Specifications

engine type 1.6L	EcoBoost I-4
engine type 2.0L	EcoBoost I-4
engine type 2.5L	i-VCT I-4
displacement 1.6L	97.6 cu. in.
displacement 2.0L	122 cu. in.
displacement 2.5L	152 cu. in.
horsepower 1.6L	178 @ 5700 rpm
horsepower 2.0L	240 @ 5500 rpm
horsepower 2.5L	168 @ 6000 rpm
torque 1.6L	184 lb.-ft. @ 2500 rpm
torque 2.0L	270 lb.-ft. @ 3000 rpm
torque 2.5L	170 lb.-ft. @ 4500 rpm
compression ratio 1.6L	10.0:1
compression ratio 2.0L	9.3:1
compression ratio 2.5L	9.7:1
bore and stroke 1.6L	3.11 x 3.20 inches
bore and stroke 2.0L	3.44 x 3.27 inches
bore and stroke 2.5L	3.50 x 3.94 inches
fuel system 1.6L	Direct Injection
fuel system 2.0L	Direct Injection
fuel system 2.5L	Sequential Multiport Injection

Weight and Dimensions

wheelbase	105.9 inches
length	178.1 inches
height	66.3 inches
width with mirrors	81.8 inches
width without mirrors	72.4 inches
track front	61.5 inches
track rear	61.6 inches
ground clearance	7.9 inches
