3-13
3.4.1 Setting up basic function codes quickly -- Menu #0 "Quick Setup" --
Menu #0 "Quick Setup" in Programming mode allows you to quickly display and set up a basic set of
function codes specified in Chapter 5, Section 5.1, "Function Code Tables."
To use Menu #0 "Quick Setup," you need to set function code E52 to "0" (Function code data editing
mode) or "2" (Full-menu mode).
The predefined set of function codes that are subject to quick setup are held in the inverter.
Listed below are the function codes (including those not subject to quick setup) available on the
FRENIC-Multi.
Table 3.11 Function Codes Available on FRENIC-Multi
Function code
group
Function codes Function Description
F codes F00 to F51
Fundamental
functions
Functions concerning basic motor running
E codes E01 to E99
Extension terminal
functions
Functions concerning the assignment of
control circuit terminals
Functions concerning the display of the LED
monitor
C codes C01 to C53 Control functions
Functions associated with frequency
settings
P codes P01 to P99 Motor 1 parameters
Functions for setting up characteristics
parameters (such as capacity) of the motor
H codes H03 to H98
High performance
functions
Highly added-value functions
Functions for sophisticated control
A codes A01 to A46 Motor 2 parameters
Functions for setting up characteristics
parameters (such as capacity) of the motor
J codes J01 to J92
Application
functions
Functions for applications such as PID
control
y codes y01 to y99 Link functions Functions for controlling communication
o codes o01 to o59 Optional functions Functions for options (Note)
(Note) The o codes are displayed only when the corresponding option is mounted. For details of the o codes,
refer to the Instruction Manual for the corresponding option.
For the list of function codes subject to quick setup and their descriptions, refer to Chapter 5,
Section 5.1 "Function Code Tables."
Through a multi-function keypad, you can add or delete function codes that are subject to
Quick Setup. For details, refer to the "Multi-function Keypad Instruction Manual."
Once you have added or deleted function codes for Quick Setup through a multi-function
keypad, they will remain valid even after you switch to a standard keypad. To restore the
function code settings subject to Quick Setup to their factory defaults, initialize the whole
data using function code H03 (data = 1).
