Fujitsu ScanSnap S510 User Manual

2.2 Connecting the ScanSnap to your PC
ScanSnap S510 Operator's Guide 23
Connecting the ScanSnap
2
■ Connecting the USB Cable
Connect the USB cable as shown below.
Operation
1. Remove the seal on the back side of the ScanSnap.
2. Connect the USB cable to the USB connector on the ScanSnap, and the other end of
the USB cable into the USB port on your personal computer.
Insert the USB cable into the connector all the way to the end.
ATTENTION
• Use only the USB cable supplied with the Scanner.
• When connecting to a USB hub, be sure to connect the ScanSnap to the hub
nearest your personal computer (first stage). If you connect it to a USB hub
from the second stage onwards, the ScanSnap may not function correctly.
• If you connect the ScanSnap with USB 2.0, it is required that the USB port and
the Hub be compliant with USB 2.0. The scanning speed may slow down
when you connect the ScanSnap with USB 1.1. If your computer has the USB
2.0 compatible port, use it.
DC 16V
Seal
USB cable
USB cable

Fujitsu ScanSnap S510 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum storage drive space	512 MB
Minimum system requirements	Windows 2000/ XP/ Vista
Sustainability certificates	ENERGY STAR
Power requirements	AC 100V to 240V, 50 / 60 Hz
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
