1. OPERATIONAL OVERVIEW
1-23
5. Select [2 DATE-TIME], then select [UTC] or [LOCAL] as appropriate.
• [UTC]: Date and time are displayed in UTC format.
• [LOCAL]: Date and time are shown with the local time offset applied.
If you selected [UTC], close the menu. If you selected [LOCAL], go to step 6.
6. Select [3 ADJUST LOCAL TIME].
7. Spin the scrollwheel, or use the number keys to input the desired offset.
The offset must be in 30 minute increments.
Note: Regarding input for [3 ADJUST LOCAL TIME], when using the number
keys, the indication is first selected as a whole. At this time, you can toggle be-
tween plus “+” or minus “-”. Press the 8 key for “-”, press the 2 key for “+”. If single
digits are highlighted, toggle is not possible. In this case, press the CANCEL
TRAILS key to re-highlight the whole indication.
8. Close the menu.
1.15 User Settings
The user functions shown in the table below can be reset to their default settings by
enabling the [PILOT SETTING] option in the [USER SET] menu. Functions not shown
in the table below maintain their previous setting.
The unit can store two separate user settings, for the functions listed below, in the in-
ternal memory. These settings can also be recalled. Functions not shown in the table
below cannot be stored or recalled.
Function Setting(s) Menu/On-screen box
GAIN Maintained as per
previous setting.
[GAIN] box
SEA [MAN], the setting
value is maintained
as per previous set-
ting.
[SEA] box
RAIN [RAIN] box
TUNE [AUTO] [TUNE] box (Magnetron radars only)
TX CH Maintained as per previous setting. (Solid State radars on-
ly)
Range [6 NM] [RANGE] box
Range rings [OFF]
[MAIN MENU]
→ [3 NAV TOOLS] →
[4 RANGE RINGS]
VRM1 Display [ON] [VRM1] box
Distance [0.250 NM]
Time indication highlighted as a whole.
Toggle between “+” and “-” is possible.
Single digit is highlighted. Toggle
between “+” and “-” is not possible.
