3-2
3.2 SYSTEM SETTING Menu
This menu mainly sets picture layout parameters.
DISP ALM TX/RX USER-1/2 SYSTEM
Select system language.
[-/+]: Change set, [EXIT (knob)]: Exit
SYSTEM SETTING
LANGUAGE : ENGLISH
PICT ADV DIR : LEFT
DEPTH SCALE : RIGHT
DISP DIVISION :
ZOOM MARKER : ON
FREE SHIFT : OFF
ECHO STRETCH : OFF
DEPTH UNIT : ft
SPEED UNIT : kt
TEMP UNIT : ˚F
BOTTOM LEVEL :+0 (-40 ~ +40)
RANGE HOLD : 4(4 - 20)
Setting may be changed when
AUTO SHIFT in the DISP menu
is turned on.
SYSTEM SETTING menu
LANGUAGE
Selects the language, ENGLISH or JAPANESE. After making selection, rotate the [FUNCTION]
switch to select EXIT. This permits switching of language.
PICT ADV DIR
Selects picture advance direction to left, right or left/right which advances the picture in both
right and left directions from the screen center.
DEPTH SCALE
Selects where to position the depth scale; right, center or off.
DISP DIVISION
Sets screen division for the dual picture. vertically divides the screen; horizontally
divides the screen.
To Next Page
