5-6
5.5 Test Pattern
The test pattern tests for proper display of colors.
1. Rotate the [FUNCTION] switch fully clockwise to select MENU.
2. Press the [] key to select the menu title area at the top of the screen.
3. Press the [+] key to select SYSTEM.
4. Press the [] or [] key to select TEST.
5. Press the [+] key.
6. Press the [+] key to select TEST PATTERN.
7. Press the [+] key twice to select YES in the dialog box.
[ ] : YES[ ] : NO
Test pattern selection dialog box
8. Press the [+] key to change the test pattern.
The test pattern changes in the sequence below.
BLUE GREENBLACK
WHITE
RED
16 tones
of RED
16 tones
of GREEN
16 tones
of BLUE
Test pattern sequence
9. Press the [MARKER/TLL] key more than three seconds to return to the system menu.
10. Rotate the [FUNCTION] switch fully counterclockwise to select EXIT.
