3.10 TARGET ECHO SETTING Menu
The TARGET ECHO menu sets equipment objective. Four choices are available: NORMAL,
SURFACE, SQUID and DEEP SEA.
DISP ALM TX/RX USER-1/2 SYSTEM
Select target echo to optimize
sounding parameters.
[-/+]: Change set, [EXIT (knob)]: Exit
TARGET ECHO : NORMAL
TARGET ECHO
SURFACE is valid when proper
transducer is connected.
TARGET ECHO menu
Note: Select SURFACE only when both of the transducers (1 kW) below are used. The
SURFACE can be used to detect small surface fish. The pulse repetition rate is greater than
NORMAL.
•
50/200-1ST
•
50/200-1T
•
200B-5S
•
50B-6
•
50B-9/9B
•
50B-8G
•
50/200/400
