3-4
RANGE HOLD
RANGE HOLD, effective when AUTO SHIFT in the DISP menu is turned on, sets the number of
transmissions (4-20) to wait before changing the range when the bottom is lost. Change the
setting when it is necessary to have the range changed often (for example, the distance to the
bottom changes suddenly) or it is difficult to keep the bottom echo “connected.”
3.3 ES/DRAFT SETTING Menu
This menu sets up the transducer and ship’s draft.
DISP ALM TX/RX USER-1/2 SYSTEM
Select transducer connected.
[-/+]: Change set, [EXIT (knob)]: Exit
ES/DRAFT SETTING
<High Frequency>
<Low Frequency>
*
*: FCV-1200L only
XDCR CONNECT : INTERNAL
TX POWER : MAX
DRAFT : +0.0 ft (-15 +90)
FREQ CHOICE : 75 kHz
XDCR CONNECT :INTERNAL
TX POWER : MAX
DRAFT : +0.0 ft (-15 +90)
FREQ CHOICE : 22 kHz
E/S SIG OUT : OFF
KP SETTING : INTERNAL
*
ES/DRAFT SETTING menu
XDCR CONNECT (High and Low Frequencies)
Sets the video sounder to be used for the high and low frequencies, as follows.
INTERNAL: Use the internal video sounder signal (FCV-1200L only).
ETR: Use the video sounder signal from the external Transceiver unit (FCV-1200LM and
FCV-1200L with optional EXIF assy. only).
TS/OTHER: Use the video sounder signal from the external telesounder, video sounder or
sonar (FCV-1200LM and FCV-1200L with optional EXIF assy. only).
Note: Choose INTERNAL when selecting LF, HF or LF/HF at the ES SIG OUT described on the
next page.
