Furuno GP-150 Installation Manual

8. MENU SETTINGS
8-10
Loading completed
Valid waypoint : 0
Invalid waypoint : 0
Press any key
Figure 8-21
8) Press the [MENU ESC] key twice.
Saving data to personal computer
Waypoint and route data can be saved to a
personal computer.
1) Press MENU ESC, 9 and 5.
2) Press
or to select Level.
3) Press
or to select level; RS232C
or RS422.
4) Press the NU/CU ENT key. "Data"
appears in reverse video.
5) Press
to select Com.
6) Press
to select Next Page.
7) Press
or to select Baud Rate.
8) Press
or to select baud rate;
4800bps, 9600bps, or 19200bps.
9) Press
to select Command (under the
Save Data line). Stop, on the same line
as Command, appears in reverse video.
10) Press
to select Start. The message
shown in Figure 8-22 appears.
Are you sure to save ?
ENT: Yes MENU:No
Figure 8-22
11) Press the NU/CU ENT key. The message
shown in Figure 8-23 appears while data
is being saved.
Now saving
Waypoint/Route data !
MENU:Stop
Figure 8-23
12) Save data at the computer.
13) Press the MENU ESC key. When data is
saved, the cursor shifts to Stop.
14) Press the MENU ESC key.
8.6 WAAS/DGPS Setting
This menu sets the using WAAS or when the
DGPS beacon receiver GR-80 is connected.
The default setting is “GPS”.
WAAS
1) Press MENU ESC, 9 and 7 to display the
WAAS/DGPS SETUP menu.
WAAS SEARCH Auto Man (GEO=134)
Freq. 323.0kHz
Baud Rate 200 bps
WAAS/DGPS SETUP
MENU : Escape
ENT : Enter
: Select
MODE Of
GPS Of
CORRECTIONS DATA SET : 00
DGPS Station Auto Man (ID=0274)
Figure 8-24 WAAS/DGPS SETUP menu
2) Press
or to select WAAS or AUTO.
3) Press
to select WAAS SEARCH.
4) Press
or to select Auto or Man.

Furuno GP-150 Specifications

General

Display Type	LCD
Display Size	4.5 inches
Resolution	320 x 240 pixels
Channels	12
Operating Temperature	-15°C to +55°C
Waterproof Rating	IPX5
Data Output	NMEA 0183
Type	GPS Receiver
Accuracy	10 meters
Languages	English
