Furuno GP-150 Installation Manual

6. INITIAL SETTINGS
17
AGFPA: Autopilot information from FURUNO autopilot equipments
Port Input Output
DATA1
DATA2
NMEA 0183
Ver. 1.5 /2.0
AGFPA , DBT, DPT, HDG,
HDM, HDT, MTW, TLL, VBW,
VHW
IEC 61162-1/NMEA 0183 Ver.1.5/
Ver.2.0
AAM, APA, APB, BOD, BWC, BWR,
BWW, GGA, GLL, GNS, RMB, RMC,
VDR, VTG, WCV, WPL, XTE, ZDA,
GBS, Rnn, RTE, DTM
LOG PULSE DATA3 External MOB
Same as the data output form “DATA1”
General data DATA4 DGPS or general data (Selected
by menu)
IEC 61162-1/NMEA 0183 Ver.1.5/
Ver.2.0
AAM, APA, APB, BOD, BWC, BWR,
BWW, GGA, GLL, GNS, RMB, RMC,
VDR, VTG, WCV, WPL, XTE, ZDA,
GBS, Rnn, RTE
Note: BWC, BWR, GGA, GLL, RMB, RMC or WPL is required to output DTM.
General data
1) Input of waypoint data
Connect YEOMAN equipment to DATA4 port.
2) Input and output of waypoint / route data
TX Rate of operation
The TX rate of operation is the percentage of data output in one second, and it appears on
the screen. Refer to page 18. If short intervals are assigned to many sentences, the rate of
operation increases as illustrated below
TX TX TX
TX rate of operation: Low
TX
TX
TX
TX
TX
TX rate of operation: High
Note 1: When outputting data without rest intervals between data, TX rate of operation is
100%. In this case, wrong data may be shown on the receiver because it cannot
recognize intervals between data. Thus, do not output unnecessary data or set TX
interval to large value so that TX rate of operation becomes small.
Note 2: When the external equipment cannot display correct data input from the GP-150,
the rate of operation should be lowered. For example, set a rate of operation less
than 60 % for the Temperature Indicator TI-20.
