Furuno GP-150 Installation Manual

12
6. INITIAL SETTINGS
Checking Operation
1. Turn on the GP-150.
2. Confirm that "OK" and "BEACON RCVR INSTALLED" are displayed on the self-test
display.
Confirm that "BEACON RCVR
INSTALLED" is displayed when
DGPS function is provided.
BEACON RCVR INSTALLED
DATA 3: DATA OUTPUT
PROGRAM MEMORY =OK
SRAM =OK
=OK
Internal Battery
Self-test display at equipment start up
3. Press MENU ESC, 8 and 1. Confirm that "OK" are displayed for PROGRAM MEMORY,
SRAM, Internal Battery, GPS and BEACON.
DGPS Setup
The default setting is "manual".
Automatic DGPS setup
GP-150 can automatically select optimum reference station. If it takes more than five (5)
minutes to fix DGPS position at the automatic mode, switch to manual mode. Use the
manual mode when an external beacon receiver has no automatic function of station
selection.
1. Press MENU ESC, 9 and 7 to display the WAAS/DGPS SETUP menu.
These items appear when
"Man" is selected.
WAAS/DGPS SETUP
Freq.
288.0kHz
ENT: Enter MENU: Escape
Baud Rate
200 bps
MODE
WAAS SEARCH Auto Man (GEO= )___
:Select
GPS
CORRECTIONS DATA SET 00
DGPS Station
Auto
___
(ID= )
Man
Not used.
 DGPS SETUP menu
2. Press
S or T to select MODE and press W to select INT BEACON.
3. Press
S or T to select DGPS Station.
4. Press
W to select Auto.

Furuno GP-150 Specifications

General

Display Type	LCD
Display Size	4.5 inches
Resolution	320 x 240 pixels
Channels	12
Operating Temperature	-15°C to +55°C
Waterproof Rating	IPX5
Data Output	NMEA 0183
Type	GPS Receiver
Accuracy	10 meters
Languages	English
