Garland Mealstream CTM3 User Manual

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 17
12
No. Description All models
12 Door Hinge Assembly LH 11C0167
16 Door Hinge Assembly RH 11C0166
51 Pin 790027
52 Roller 40C0752
53 M5 Hex/hd s/s Screw 101825
54 M5 stainless steel Nut 80X7003
55 LH Hinge bracket 790024
56 RH Hinge bracket 790025
58 Stirrer motor assembly 11C0324
( not shown in main views )
54
53
53
54
Right Hand Door Hinge
Assembly
Left Hand Door Hinge
Assembly
55
Stirrer motor assembly
58
52
51
16
51
56
52
PRINCIPAL COMPONENTS
