Garland Mealstream CTM3 User Manual

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 51
APPENDIX 6: Recommended spares list
Part
Number
Description
Quantity
per kit
11M0417 HT DIODE PCB ASSY 2
11C0292 CTM3 DOOR SEAL SET 1
11C0319 STIRRER GLASS ASSY 1
11C0324 STIRRER MOTOR ASSY WIDE DIST 1
11C0377 MEALSTREAM 501 LOGIC PCB ASSY 1
11C0402 CTM5 RELAY PCB ASSEMBLY 208V 1
30Z0217 FUSE 1in 10A HRC 10
30Z0231 FUSEHOLDER 1in (13A) 3
30Z0283 470R 50W 5% AC 1
30Z0503 SWITCH ON/OFF ROCKER DPST 1
30Z0957 FUSE 1x1/4in 1A HBC (MAINS) 3
30Z0997 FILTER 16A 2
30Z1145 DOUBLE BLOWER FAN 208V 60HZ 1
30Z1177 20 AMP LITTELFUSE FLM020 10
30z1178 30A FUSE HOLDER 2
30Z1230 60HZ TRANS MULTI 208 220 240 1
790052 RED SILICON SEAL LH/RH 3 metres
2571016 THERMAL CUT OUT 125C 2
10C0171 DOOR SPACER KIT 1
30Z1024 OVERHEAT SAFETY STAT 1
40C1141 DOOR SPRING(LARGE) MSTREAM 501 2
50E123 THERMISTOR 1
40C0949 HEATER ELEMENT 3.0 KW 208V 1
30Z1171 MAGNETRON PANASONIC 2M244 2
10C0192 M/EALSTREAM 501 HOT AIR MOTOR 1
11C0412 MEMBRANE ON SUBS TH 1/4 E ASSY 1
11C0481 MICROSWITCH REPLACE KIT EC501 2
10C0172 CAPACITOR KIT: 30Z1251 0.88uF 2500V and clips 2
40C1113 ROOF CORNER CAP 4
11C0482 SCREW FIXING KIT EC501/2/3 1
Item
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Recommended spares list (to support 1– 3 ovens)
Available as complete kit on part number 10C0244 (208V 60Hz)
