Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 30
Item No. Description Part No. Quantity
1 RHS door hinge assy 11C0166 1
2 M5 x 10mm 101820 4
3 M5 flat washer 31Z5008 29
4 M5 shake proof washer 31Z5012 29
5 Spacer 790084 2
6 M5 x 16mm hex screw 101876 2
7 Door frame assy 11C0303 1
8 LHS door hinge assy 11C0167 1
9 Door arm assy 11C0300 2
10 Door arm Pivot Pin 790010 2
11 Door spring 520000 or 40C1141 2
12 Door Stop 40C0854 2
13 Door stop spring clip 31Z5047 2
14 M5 stainless steel full nut 80X07003 23
15 Door seal set of 4 11C0292 1
16 CAF 30 Adhesive 31Z0186 As required
17 Door insulation set 40C0942 1
18 Outer Door Skin Check Oven Model 1
19 M3 counter sunk screw 31Z3094 7
20 Choke Plate 790007 1
21 SPACER KIT 10C0171 1
Tools required for door fitting
M5 Nut runner Door Spacers S325 & 3 off S215
Flat head screw driver Long nose pliers
5mm open-ended spanner Adhesive skeleton gun
Engineers rule
Please Note
DO NOT attempt to carry out the following procedure
unless you have the following tools and parts.
Parts required for door fitting
PROCEDURE FOR BUILDING AND FITTING MEALSTREAM DOOR (1)
To Next Page
